Table 65: I OUTPUT connector pin assignment (cont.)
Pin number Signal name Description
2
EXT_IQ_MSW–
27
EXT_IQ_MSW+
Reserved for future use
3 EXT_I0–
28 EXT_I0+
I output data (bit 0), LVDS
4 EXT_I1–
29 EXT_I1+
I output data (bit 1), LVDS
5
EXT_I2–
30 EXT_I2+
I output data (bit 2), LVDS
6 EXT_I3–
31 EXT_I3+
I output data (bit 3), LVDS
7
GND
32
GND
Ground
8 EXT_I4–
33 EXT_I4+
I output data (bit 4), LVDS
9 EXT_I5–
34 EXT_I5+
I output data (bit 5), LVDS
10 EXT_I6–
35 EXT_I6+
I output data (bit 6), LVDS
11 EXT_I7–
36 EXT_I7+
I output data (bit 7), LVDS
12
GND
37
GND
Ground
13 EXT_I8–
38 EXT_I8+
I output data (bit 8), LVDS
14 EXT_I9–
39 EXT_I9+
I output data (bit 9), LVDS
15 EXT_I10–
40 EXT_I10+
I output data (bit 10), LVDS
16 EXT_I11–
41 EXT_I11+
I output data (bit 11), LVDS
17
GND
42
GND
Ground
18 EXT_I12–
43 EXT_I12+
I output data (bit 12), LVDS
19 EXT_I13–
44 EXT_I13+
I output data (bit 13), LVDS
