Kit description
Kit parts list
The following table provides a list of parts contained in this k it. The kit contains
the same parts, regardless o f which of the three options you ordered. The actual
option (or options) available is controlled with the option key provided in the kit.
Quantity Part number Description
1 075-1061-X
X
MANUAL, TECH INSTALLATION, RSA5BUP OPTIONS 65,
66, 6566
1 171-2191-
XX
MANUAL,TECH; SVCPT-UPG; TEKTRONIX
SUPPLEMENTAL INFORMATION SHEET FO R
THE PEOPLE
S REPUBLIC OF CHINA; CHINA ROHS
2 174-5106-XX
CABLE, ASSEMBLY (I AND Q O UT, PANEL MOUNT),
SAFETY CO
NTROLLED
2 174-5195-XX
CABLE ASSY ELEC: 2X 50P MDR CONN. 1.5M L, 18
TWIST PA
IR, 100 OHM, 1 I/O, 13 GND, W/SHIELD
NOTE. These cables are not needed to install the Option.
They are supplied for external connections to the I and Q
Output
connectors.
1 174-5213-XX
CABLE ASSY, RIBBON; STATIC GROUND, 1X2; SAFETY
CONTR
OLLED
1 174-6418-XX
CABLE, COAX BNC-ST TO SMB-RA
1 200-
5317-XX
COVER, REAR PANEL, OPTION (I AND Q / ZERO SPAN)
4 211-0450-XX
SCRE
W, MACHINE ; 2.5MM X 0.45 X 6MM, PNH, STEEL,
ZINC PLATED, T8 TORX DRIVE
8 211-1050-XX
SCR
EW, MACHINE; 6-32 X 0.312 L, PNH, STEEL, ZINC
FINISH, T15
1 863-0955-XX
CK
T BD SUBASSY; REAL TIME IQ AND LOG VIDEO
OUTPUT, FUNCTIONALLY TESTED
1
N
/A
L
ABEL, EXPORT CO NTROL CLASSIFICATION
NOTE. Export c ontrol label only applies to RSA5100B
Series instruments when installing Option 65 or Option 6566.
1
N/A LABEL, MANUFACTURED; OPTION KEY UPGRADE
LABEL
1
N/A LABEL, MANUFACTURED; PRODUCT LABEL, SAFETY
CONTROLLED
RSA5100A/B Series Digital I/Q and Zero Span Upgrades 3
