Tektronix RSA5103 Technical Reference

Performance Verification
Table 73: Low Fr
equency input path flatness
Attenuator = 1
0dB
Frequency
Power meter
reading
∆ Power meter
(vs. 10 MHz) RTSA reading
∆ RTSA reading
(vs. 10 MHz)
RF flatness
error
1
10 MHz 0 0 0
11 MHz
12 MHz
13 MHz
14 MHz
15 MHz
16 MHz
17 MHz
18 MHz
19 MHz
20 MHz
21 MHz
22 MHz
23 MHz
24 MHz
25 MHz
26 MHz
27 MHz
28 MH
z
29 MHz
30 MHz
31 M
Hz
31.49 MHz
1
UsetheformulainStep16
18. Ent
er the largest variation in each of the following frequency range into the
test record:
10
MHz - 32 MHz
RSA5100B Series Technical Reference 97
