Tektronix RSA5103 Technical Reference

Performance Verification
Displayed Average Noise Level (DANL) Test Result High limit
Preamp ON
1MHz-32MHz
(LF B and,
RSA5103B/5106B)
–158 dBm/Hz
1MHz-10MHz
–158 dBm/Hz
10 MHz - 2 GHz –164 dBm/Hz
2 GHz - 3 GHz –163 dBm/Hz
3GHz-6.2GHz
(RSA5106
B)
–162 dBm/Hz
3GHz-4GH
z
(RSA5115B/5126B)
–160 dBm/
Hz
4GHz-6.2GHz
(RSA5115B/5126B)
–159 dBm/Hz
Normalized to
1Hz
RBW, with log-average
detector
6.2GHz-13GHz
(RSA51
15/5126B)
–159 dBm/Hz
13 GHz
–23GHz
(RSA5115/5126B)
–157 d
Bm/Hz
23 GHz - 26.5 GHz
(RSA5126B)
–153 dBm/Hz
IF Flatness (Channel Response) Low limit Test Result Hig h limit
Span Setting
300 kHz –0.1 dB +0.1 dB
20 M
Hz
–0.
3dB
+0.
3dB
25 MHz –0.3 dB +0.3 dB
85 MHz (Option B85
on
ly)
–0.5 dB +0.5 dB
1
60 MHz (Option B16x
only)
–0.5 dB +0.5 dB
R
esidual Response
T
est Result
H
igh limit
2
00 MHz – 3 GHz (RSA5103B)
–95 dBm
200 MHz – 6.2 GHz (RSA5106B)
–95 dBm
200 MHz – 15 GHz (RSA5115B)
–95 dBm
200 MHz – 26.5 GHz (RSA5126B)
–95 dBm
RSA5100B Series Technical Reference 137
