Tektronix RSA5103 Technical Reference

Performance Verification
Image Suppression Test Result High limit
All Models
10 kHz to <30 MH
z(LF
Path)
–75 dBc
30MHzto3GHz
–75 dBc
RSA5106B/5115B/5126B
3GHzto6.2GHz
(RSA5106B/5115B/5126B)
–70 dBc
6.2 GHz to 15 GHz
(RSA5115
B/5126B)
–76 dBc
15 GHz to 2
6.5 GHz
(RSA5126B)
–72 dBc
Spurious Response with Signal Low limit Test Result High limit
>400 kHz of Center Frequency
Fail Pass
>400 kHz of Center Frequency (Option B85 only)
Fail Pass
>400 kHz of Center Frequency (Option B16x only)
Fail Pass
