Circuit
Description-T921/T922/T922R

XI
.
1
Diagrams
7,
8, 9,
and
associated
circuit
descriptions
pertain
to
circuitry
that
is
used
only
in
the
T922R
and
is
not
present
in
the
T921
and
T922
bench
versions
.
For
circuit
descriptions
and
diagrams
of
circuitry
common
to
the
T921, T922,
and
T992R,
refer
to
diagrams
1
through
6
.
SCALE
ILLUMINATION
AND
+32
VOLT
POWER
SUPPLY
The
T921
and
T922
bench
versions
use a
dropping
resistor
R784
and
Zener
diode
VR784
to
drop
the
+100
volt
supply
to
+33
volts
for
use
in
the
Vertical
Output
Amplifier
and
crt
circuits
(see
Fig
.
7-4)
.
In
the
T922R,
the
Scale
Illumination
circuit
provides a
+32
volt
supply
in
place
of
the
+33
volt
supply
.
VR818
holds the
base
of
Q812
at
+33
volts
.
This holds the
output
voltage
at
about
+32
volts
.
When
the
SCALE
ILLUM
control
(R812)
is
set
fully
counterclockwise,
Q816
and
Q818
are
biased
off
and
transistor
Q812
supplies
all
the
current
drawn
by
the
+32
volt
supply
.
To
increase
Scale
Illumination,
R812
is
adjusted
to
forward
bias
0816
and
0818
.
As
this
forward
bias
increases,
the
current
through
them
increases
.
This
causes
a
corresponding decrease
in
the
current
through
Q812
.
The
increased
current
through
Q816
increases
the
current
through
DS816
and DS818,
which
increases
scale
illumination
.
R784
10
WATT
REV
.
A,
JUNE
1976
+100V
+33V
I
VERTICAL
OUTPUT
AMPLIFIER
1982-63
Fig
.
7-4
.
Bench
version
T922
+33
volt
power
supply
.
T922
R
VERTICAL
SIGNAL
OUT
(COMP
VERT
SIG
OUT)
Fig
.
7-5
shows
a
simplified
block
diagram
of
the
Vertical
Signal
Out
circuit
.
The
Vertical
Signal
Out
circuit
supplies
a
sample
of
the signal
present
in
the
Vertical
Output
Amplifierto
J169
(COMP
VERT
SIG
OUT)
on the
rear
panel
.
Q160
and
Q162
are
connected
as a
differential
amplifier
.
The
paraphase
signal
from
the
emitters
of
0112
and
Q122
(see
diagram
1)
is
applied
totheinputsofthedifferential
amplifier
(the
bases
of
Q160
and
Q162
respectively)
.
The
output
of
the
differential
amplifier
is
taken
from
the collector
of
Q162
and
applied
to
the
base
of
Q166
.
Transistor
Q166
amplifies
the
output
signal
and
shifts
its
do
level
.
The
signal
from
the collector
of
Q166
is
connected
(through P168)
to
the
COMP
VERT
SIG
OUT
connector,
J169
.
Fig
.
7-5
.
Simplified
block
diagram
of
the
vertical
output
amplifier
circuit
.
