Appendix C: Options and Accessories
Accessory Probes
These arc other types of probes you can use with the TDDS 340, TDS 360, and
TDS
380. You
can order the following probes separately:
I P61OlB 1X Passive Probe
n
P6129B Switchable 1X-10X Passive Probe (not recommended for the
TDS 360 or TDS 380)
n
P6408 ‘IT Logic Probe
n
PS
100 High Voltage Probe
q
P5200 High-Voltage Differential Probe
m AM503S
DC/AC Current Probe System
m P6561AS SMD Small-Geometry Probe
Accessory Cables
Table C-6 lists
cables you can use
with the TDS 340, TDS 360, and ‘IDS 380.
You can order them separately.
Table C-6: Accessory cables
Cable type
GPIE.1 meter (3.3 feet)
GPIE, 2 meter (6.6 feet)
K-232, e-pin female to g-pin female connectors, null
modem, 76 inch (for AT style computers)
RS-232. g-pin female to 25pin female connectors, null
modem, 76 inch (for PC style compwers)
K-232, S-pin female to 25pin male connectors, null
modem, 9 feet (forserial interface plinks)
135-232. g-pin female to 25.pin male connectors, 15 feet
(for modems)
Centronics, 25.pin male to 36.pin Centronics,
2.4 meter (8 feet) (for parallel printer interfaces)
NEW VGA video cable. (Use an appropriate adapter
when other than a e-pin monitor connection is needed.)
Part number
012-0991-01
012.1298-00
012.1214-00
TDS 340, TDS 360 & TDS 380
User ManUd
