TDS 600B Test Record (Cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS 600B Performance Test MaximumOutgoingIncomingMinimum
Delay Between Channels
Delay Between Channels N/A __________ __________ 100 ps
Time Base System
Long Term Sample Rate/
Delay Time @ 500 ns/10 ms –2.0 Div __________ __________ +2.0 Div
Trigger System Accuracy
Pulse-Glitch or Pulse-Width,
Hor. scale ≤ 1 ms
Lower Limit
Upper Limit
3.5 ns
3.5 ns
__________
__________
__________
__________
6.5 ns
6.5 ns
Pulse-Glitch or Pulse-Width,
Hor. scale > 1 ms
Lower Limit
Upper Limit
1.9 ms
1.9 ms
__________
__________
__________
__________
2.1 ms
2.1 ms
Main Trigger, DC Coupled, Positive Slope 9.863 V __________ __________ 10.137 V
Main Trigger, DC Coupled, Negative Slope 9.863 V __________ __________ 10.137 V
Delayed Trigger, DC Coupled, Positive Slope 9.863 V __________ __________ 10.137 V
Delayed Trigger, DC Coupled, Negative Slope 9.863 V __________ __________ 10.137 V
CH1 Sensitivity, 50 MHz, Main Pass/Fail __________ __________ Pass/Fail
CH1 Sensitivity, 50 MHz, Delayed Pass/Fail __________ __________ Pass/Fail
CH1 AUX Trigger Input Pass/Fail __________ __________ Pass/Fail
CH1 Sensitivity, 1 GHz, Main Pass/Fail __________ __________ Pass/Fail
CH1 Sensitivity, 1 GHz, Delayed Pass/Fail __________ __________ Pass/Fail
Output Signal Checks
MAIN TRIGGER OUTPUT, 1 MW
High
Low
High ≥ 2.5 V __________
__________
__________
__________ Low ≤ 0.7 V
MAIN TRIGGER OUTPUT, 50 W
High
Low
High ≥ 1.0 V __________
__________
__________
__________ Low ≤ 0.25 V
DELAYED TRIGGER OUTPUT, 50 W
High ≥ 1.0 V __________
__________
__________
__________
Low ≤ 0.25 V
DELAYED TRIGGER OUTPUT, 1 MW
High ≥ 2.5 V __________
__________
__________
__________ Low ≤ 0.7 V
