Command Descriptions
2–194
TDS Family Oscilloscope Programmer Manual
COUNt
?
MASK
:
TOTal
<NR1>
MASK:COUNt:WAVEFORMS? (Query Only)
TDS 500C & 700C Only
Returns the number of waveforms that have contributed to mask counting. This
can be much smaller than the ACQUIRE:NUMACQ number since the acquire
number just counts how many triggers have been processed. The time per div
may be fast enough that 100 or more triggers are required to be processed to fill
one waveform. Even then, it may not be completely filled.
Mask
MASK:COUNt:WAVEFORMS?
COUNt
?
MASK
:
WAVEFORMS
<NR1>
MASK:COUNT:WAVEFORMS?
might return: MASK:COUNT:WAVEFORMS 286568
MASK:DISplay
TDS 500C & 700C Only
Controls whether or not defined masks are displayed on the screen. This is useful
for temporarily turning off user-defined masks without deleting them.
Mask
MASK:DISplay { OFF | ON | <NR1> }
MASK:DISplay?
Returns
Group
Syntax
Returns
Examples
Group
Syntax
