Tektronix TDS 500C Programmer's Manual

Command Groups
TDS Family Oscilloscope Programmer Manual
2–17
Table 2–9: Display Commands (Cont.)
Header Description
DISplay:COLOr:CONTRast
(TDS 6X4B & 700)
Control collision contrast
DISplay:COLOr:MAP:<item-name>:
BYCONTents
(TDS 6X4B & 700C)
Set color for math or ref waveform to the color
of the waveform content
DISplay:COLOr:MAP:<item-name>:TO
(TDS 6X4B & 700C)
Set color for math or ref waveform to specific
color index
DISplay:COLOr:PALEtte:PERSistence
(TDS 6X4B & 700C)
Set current persistence palette to a preset
persistence palette
DISplay:COLOr:PALEtte:REGular
(TDS 6X4B & 700C)
Set current palette to a preset palette
DISplay:COLOr:PALEtte:RESETALL
(TDS 6X4A & 700C)
Reset all palettes to their factory default
settings
DISplay:COLOr:PALEtte:
<palette name>:RESET
(TDS 6X4B & 700C)
Reset a selected palette to its factory default
settings
DISplay:COLOr:PALEtte:
<palette name>:<item name>
(TDS 6X4B & 700C)
Set the color of a selected item on a selected
palette
DISplay:FILTer Displayed data interpolation
DISplay:FORMat YT or XY display
DISplay:GRAticule Graticule style
DISplay:INStavu:PERSistence
(TDS 500C & 700C)
Set InstaVu persistence type – variable or
infinite
DISplay:INStavu:STYle
(TDS 500C & 700C)
Set InstaVu waveform dots or vector style
DISplay:INStavu:VARpersist
(TDS 500C & 700C)
Set InstaVu variable persistence decay time
DISplay:INTENSITy? Return intensity settings
DISplay:INTENSITy:CONTRast
(TDS 400A, 510A, 500C, & 6X0B)
Waveform intensified zone brightness
DISplay:INTENSITy:OVERALL
(TDS 400A, 510A, 500C, & 6X0B)
Set main brightness
DISplay:INTENSITy:TEXt Set text brightness
DISplay:INTENSITy:WAVEform Set waveform brightness
DISplay:MODe (TDS 500C &700C) Set normal or InstaVu display mode
DISplay:PERSistence Set variable persistence decay time
