Tektronix TDS 500C Programmer's Manual

Command Groups
2–44
TDS Family Oscilloscope Programmer Manual
Table 2–24: Waveform Commands (Cont.)
Header Description
WFMPre:ZMUlt Z-axis scale factor
WFMPre:ZOFf Z-axis offset
WFMPre:ZUNit Z-axis units
WFMPre:ZZEro Z-axis origin offset
WFMPre:<wfm>:NR_Pt Number of points in the curve
WFMPre:<wfm>:PT_Fmt Format of curve points
WFMPre:<wfm>:PT_Off Trigger position
WFMPre:<wfm>:WFId Curve identifier
WFMPre:<wfm>:XINcr Horizontal sampling interval
WFMPre:<wfm>:XUNit Horizontal units
WFMPre:<wfm>:XZEro
(TDS 500C, 600B, & 700C)
Horizontal units
WFMPre:<wfm>:YMUlt Vertical scale factor
WFMPre:<wfm>:YOFf Vertical offset
WFMPre:<wfm>:YUNit Vertical units
WFMPre:<wfm>:YZEro Offset voltage
