TDS 520A, 524A, 540A, & 544A User Manual
3Ć59
Hardcopy
You can get a copy of the digitizing oscilloscope display by using the hardco-
py feature. Depending on the output format you select, you create either an
image or a plot. Images are direct bit map representations of the digitizing
oscilloscope display. Plots are vector (plotted) representations of the display.
Different hardcopy devices use different formats. The digitizing oscilloscope
supports the following formats:
H
HP Thinkjet inkjet printer
H
HP Deskjet inkjet printer
H
HP Laserjet laser printer
H
Epson
H
DPU-411/II portable thermal printer
H
DPU-412 portable thermal printer
H
PCX (PC Paintbrush)
H
PCX Color (PC Paintbrush) (TDS 524A & TDS 544A)
H
TIFF (Tag Image File Format)
H
BMP Mono (Microsoft Windows file format)
H
BMP Color (Microsoft Windows file format) (TDS 524A & TDS 544A)
H
RLE Color (Microsoft Windows color image file format – compressed)
(TDS 524A & TDS 544A)
H
EPS Mono Image (Encapsulated Postscript, mono-image)
H
EPS Color Image (Encapsulated Postscript, color-image) (TDS 524A &
TDS 544A)
H
EPS Mono Plot (Encapsulated Postscript, mono-plot)
H
EPS Color Plot (Encapsulated Postscript, color-plot)
H
Interleaf
H
HPGL Color Plot
Some formats, particularly Interleaf, EPS, TIFF, PCX, BMP, and HPGL, are
compatible with various desktop publishing packages. That means you can
paste files created from the oscilloscope directly into a document on any of
those desktop publishing systems.
EPS Mono and Color formats are compatible with Tektronix Phaser Color
Printers, HPGL is compatible with the Tektronix HC100 Plotter, and Epson is
compatible with the Tektronix HC220 Printer.
Hardcopy Formats
