Logic Triggering
TDS 620A, 640A, & 644A User Manual
3Ć85
Define Logic
To choose the type of logic function you want applied to the input channels:
Press TRIGGER MENU ➞ Type (main) ➞ Logic (pop-up) ➞ Class (main) ➞
State (pop-up) ➞ Define Logic (main) ➞ AND, OR, NAND, or NOR (side).
See
Triggering
, on page 2-13.
See
Triggering
, on page 3-142.
For More
Information
