Probe Accessories
TDS 520A, 524A, 540A, & 544A User Manual
3Ć99
Marker Ring
(Standard)
Marker Ring
(Standard)
IC Protector Tip
(Optional)
Dual Lead Adapter
(Optional)
Probe Tip-to-Circuit
Board Adapter
(Standard)
Probe Tip-to-Chassis
Adapter (Optional)
Retractable Hook Tip
(Standard)
KlipChip
TM
(Standard)
Slip-on
Ground Lead
(Standard)
Alligator Clip
Ground Lead
(Standard)
Low Inductance
Ground Lead
(Standard)
Low Inductance
Spring Tip (Optional)
Compact-to-Miniature
Probe Tip Adapter
(Optional)
Figure 3-53: Probe Accessories
