Waveform Integration
Reference
3Ć158
Zoom
Once you have your waveform optimally displayed, you may magnify (or
reduce) it vertically and horizontally to inspect any feature you desire. Just be
sure the integrated waveform is the selected waveform. (Press MORE, then
select the integrated waveform in the More main menu. Then use the Vertical
and Horizontal SCALE knobs to adjust the math waveform size.)
If you wish to see the zoom factor (2X, 5X, etc.) you need to turn Zoom on:
press ZOOM ➞ On (side). The vertical and horizontal zoom factors appear
on screen.
Whether Zoom is on or off, you can press Reset Zoom Factors (side) to
return the zoomed integral waveform to no magnification.
See
Waveform Differentiation
, on page 3-150.
See
Fast Fourier Transforms
, on page 3-38.
See
Waveform Math
, on page 3-159.
For More
Information
