Reference
3Ć12
Color (TDS 524A & TDS 644A)
The TDS 524A & TDS 644A can display information in different colors. The
Color menu lets you choose palettes of colors and decide what colors to
assign to what pieces of information.
To bring up the Color menu:
1. Press DISPLAY to show the Display menu.
2. Press Settings in the main menu until you select Color from the pop-up
menu (see Figure 3-4).
Figure 3-4: Display Menu — Setting
Color lets you alter color settings for various display components such as
waveforms and text. Display lets you adjust the style, intensity level, grati-
cule, and format features. For more information on display, see
Display
on
page 3-28.
Operation
