Command Descriptions

2–50

TDS Family Oscilloscope Programmer Manual

ALIas:DELEte (No Query Form)

Removes a specified alias. This command is identical to ALIas:DELEte:NAMe.

Alias

ALIas:DELEte <QString>

<Space>

ALIas

DELEte

<QString> is the name of the alias you want to remove. Using ALIas:DELEte

without specifying an alias causes an execution error. <QString> must be a

previously defined alias.

ALIAS:DELETE "SETUP1"

deletes the alias named SETUP1.

ALIas:DELEte:ALL (No Query Form)

Deletes all existing aliases.

Alias

ALIas:DELEte:ALL

ALIas

DELEte

ALL

ALIAS:DELETE:ALL

deletes all aliases.

ALIas:DELEte:NAMe (No Query Form)

Removes a specified alias. This command is identical to ALIas:DELEte.

Alias

ALIas:DELEte:NAMe <QString>

Group

Syntax

Arguments

Examples

Group

Syntax

Examples

Group

Syntax
