TDS1000 and TDS2000 S eries Digital Storage Oscilloscopes Service Manual
Table 1- 1: Oscilloscope specifications (Cont.)
Horizontal
Sample Rate Range TDS2022, TDS2024 TDS1001, TDS1002, TDS2004, TDS1012, TDS2002,
TDS2012, TDS2014
5S/sto2GS/s 5S/sto1GS/s
Waveform Interpolation (sin x)/x
Record Length 2500 samples for each channel
SEC/DIV Range TDS2022, TDS2024 TDS1001, TDS1002, TDS2004, TDS1012, TDS2002,
TDS2012, TDS2014
2.5 ns/div t o 50 s/div, in a 1, 2.5, 5 sequence 5 ns/div to 50 s/div, in a 1, 2.5, 5 sequence
n Sample Rate and
Delay Time Accuracy
±50 ppm over any ≥1 ms time interval
Delta Time Measurement Conditions Accuracy
Accuracy (Full Band-
w
i
d
t
h
)
Single-shot, Sample mode ±(1 sample interval + 50 ppm × reading + 0.6 ns)
w
i
d
t
h
)
> 16 averages ±(1 sample interval + 50 ppm × reading + 0.4 ns)
Sample interval = s/div ÷ 250
Position Range 5ns/divto10ns/div (--4 div × s/div) to 20 ms
g
25 ns/div to 100 s/div (--4 div × s/div) to 50 ms
250 s/divto50s/div (--4 div × s/div) to 50 s
TDS2022, TDS2024
2.5 ns/div (--4 div × s/div) to 20 ms
