Tektronix TDS1012 Programmer's Manual

Command Descriptions
2−148
TDS200/1000/2000 Series Oscilloscope Programmer Manual
TRIGger:MAIn:PULse:WIDth:WHEN?
EQual triggers on the trailing edge of pulses of the specified width.
NOTEQual triggers when a pulse’s trailing edge occurs before the
specified width, or a pulse continues longer than the specified width
without a trailing edge.
INside (less than) triggers on the trailing edge of any pulses that are
narrower than the specified width.
OUTside (greater than; also called time-out trigger) triggers when a
pulse continues longer that the specified width.
TRIGger:MAIn:PULse:WIDth:WIDth
NOTE. You can use this command ONLY with the TDS1000 and
TDS2000 series.
Sets or queries the width for the pulse trigger. This is equivalent to
setting the Width option by using the Pulse Trigger menu and the
TRIGGER knob.
Trigger
TRIGger:MAIn:PULse:WIDth:WIDth < NR3 >
TRIGger:MAIn:PULse:WIDth:WIDth?
Time, in seconds. Range is 33 ns to 10 s. Resolution varies. Value is
forced to nearest achievable value.
Arguments
Group
Syntax
Arguments
