Command Groups
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−19
Table 2−12: Horizontal commands (Cont.)
Header Description
HORizontal:MAIn Set/query main time base time/division
HORizontal:MAIn:POSition Set/query main time base trigger point
HORizontal:MAIn:SCAle Set/query main time base time/division
HORizontal:MAIn:SECdiv Same as HORizontal:MAIn:SCAle
HORizontal:POSition Set/query position of waveform to display
HORizontal:RECOrdlength Return waveform record length
HORizontal:SCAle Same as HORizontal:MAIn:SCAle
HORizontal:SECdiv Same as HORizontal:MAIn:SCAle
HORizontal:VIEW Select view
Math Commands
Math commands provide math function definition. Table 2-13 lists
and describes Math commands.
Table 2−13: Math commands
Header Description
MATH? Query the definition for the math wave−
form
MATH:DEFINE Set/query math waveform definition
MATH:FFT:HORizontal:POSition
1
Set/query FFT horizontal display position
MATH:FFT:HORizontal:SCAle
1
Set/query FFT horizontal zoom factor
MATH:FFT:VERtical:POSition
1
Set/query FFT vertical display position
MATH:FFT:VERtical:SCAle
1
Set/query FFT vertical zoom factor
1
TDS1000 and TDS2000 series, or TDS200 series with a TDS2MM
measurement module.
