Command Descriptions
TDS200/1000/2000 Series Oscilloscope Programmer Manual
2−101
HORizontal:SECdiv
Sets the time per division for the main time base and is identical to
the HORizontal:MAIn:SCAle command. It is included for compati-
bility purposes.
HORizontal:VIEW
Specifies whether the horizontal display uses the Main, Window
Zone, or Window view. This is equivalent to setting the View in the
Horizontal menu.
Horizontal
HORizontal:VIEW { MAIn | WINDOW | ZONE }
HORizontal:VIEW?
MAIn specifies that the waveform is acquired and displayed using the
Main time base.
WINDOW specifies that the waveform is acquired and displayed using
the Window (delay) time base.
ZONE is the same as MAIn, but adds display of vertical cursor bars to
show the portion of the waveform that would be acquired and
displayed using the window (delay) time base.
HORizontal:VIEW MAIn
is the default view.
Group
Syntax
Arguments
Examples
