Command Descriptions
2−100
TDS200/1000/2000 Series Oscilloscope Programmer Manual
HORizontal:POSition 2.0E–6
sets the main trigger position to 2 ms before the center graticule.
HORizontal:POSition?
might return –1.0E–3, indicating that the main trigger position is 1
ms after the center graticule.
HORizontal:RECOrdlength? (Query Only)
Returns the number of acquisition data points. For TDS200,
TDS1000 and TDS2000 series oscilloscopes, this value is always
2500, even in FFT mode. This command is provided to maintain
program compatibility with other Tektronix digital oscilloscopes.
Horizontal
HORizontal:RECOrdlength?
2500
HORizontal:RECOrdlength?
returns 2500 as the number of data points in each record.
WFMPre:NR_Pt?, WFMPre:<wfm>:NR_Pt?
HORizontal:SCAle
Sets the time per division for the main time base and is identical to
the HORizontal:MAIn:SCAle command. It is included for compati-
bility purposes.
Examples
Group
Syntax
Returns
Examples
Related Commands
