Command Descriptions
2−154
TDS200/1000/2000 Series Oscilloscope Programmer Manual
LINENum (TDS1000 and TDS2000 series only) sets the oscilloscope
to trigger on a specific line number, which is specified through
TRIGger:MAIn:VIDeo:LINE.
TRIGger:MAIn:VIDeo:SYNC FIELD
selects the vertical sync pulse for the video trigger sync.
TRIGger:STATE? (Query Only)
Returns the current state of the triggering system.
NOTE. Accurate real time reporting of the trigger state within any
single waveform acquisition is limited by several factors, including
horizontal sweep speed, and communications and task latencies. To
check for the completion of a single sequence acquisition, use the
*OPC? query.
Trigger
TRIGger:STATE?
ARMED indicates that the oscilloscope is acquiring pretrigger
information. All triggers are ignored when TRIGger:STATE is
ARMed.
READY indicates that all pretrigger information has been acquired and
the oscilloscope is ready to accept a trigger.
TRIGGER indicates that the oscilloscope has seen a trigger and is
acquiring the posttrigger information.
AUTO indicates that the oscilloscope is in auto mode and acquires
data even in the absence of a trigger.
Examples
Group
Syntax
Returns
