Status and Events

3−20

TDS200/1000/2000 Series Oscilloscope Programmer Manual

Table 3−5: Execution error messages – EXE bit 4 (Cont.)

Code Message

2210 Measurement error, No Mid Ref crossing, second waveform

2211 Measurement error, No backwards Mid Ref crossing

2212 Measurement error, No negative crossing

2213 Measurement error, No positive crossing

2214 Measurement error, No crossing

2215 Measurement error, No crossing, second waveform

2216 Measurement error, No crossing, target waveform

2217 Measurement error, Constant waveform

2218 Measurement error, Unused

2219 Measurement error, No valid edge: No arm sample

2220 Measurement error, No valid edge: No arm cross

2221 Measurement error, No valid edge: No trigger cross

2222 Measurement error, No valid edge: No second cross

2223 Measurement error, waveform mismatch

2224 Measurement error, WAIT calculating

2225 Measurement error, No waveform to measure

2226 Null Waveform

2227 Positive and Negative Clipping

2228 Measurement error, Positive Clipping

2229 Measurement error, Negative Clipping

2230 Measurement error, High Ref < Low Ref

2235 Math error, Invalid math description

2241 Waveform request is invalid

2242 Data start > record length
