Adjustment Procedures
Table 5-2: Adjustment steps (cont.)
Input Setup diagram
2-ch model
step number
4-ch model
step number Signal Signal source setting
35 35
Sinewave Generator,
50 Ω
5kHz,1V
p-p
36 36
Sinewave Generator,
50 Ω
1 MHz, 100 mV
p-p
37 37
Sinewave Generator,
50 Ω
1MHz,1V
p-p
38 38
Sinewave Generator,
50 Ω
50 kHz, 1 V
p-p
39 39
Sinewave Generator,
50 Ω
20 MHz, 1 V
p-p
40 40
Sinewave Generator,
50 Ω
BWL, 25 mV
p-p
41 41
Sinewave Generator,
50 Ω
BWL, 50 mV
p-p
42 42
Sinewave Generator,
50 Ω
BWL, 100 mV
p-p
43 43
Sinewave Generator,
50 Ω
BWL, 250 mV
p-p
44 44
Sinewave Generator,
50 Ω
BWL, 500 mV
p-p
45 40
Sinewave Generator,
50 Ω
BWL, 1 V
p-p
46 46
Sinewave Generator,
50 Ω
5kHz,2.5V
p-p
47 47
Sinewave Generator,
50 Ω
1MHz,2.5V
p-p
48 48
Sinewave Generator,
50 Ω
50 kHz, 2.5 V
p-p
49 49
Sinewave Generator,
50 Ω
20 MHz, 2.5 V
p-p
50 50
Sinewave Generator,
50 Ω
BWL, 2.5 V
p-p
51 51
Sinewave Generator,
50 Ω
BWL, 5 V
p-p
Sinewave
generator
52 52
Sinewave Generator,
50 Ω
BWL, 1.6 V
p-p
Ch 1
Edge 53 53
Edge, 50 Ω.
1 kHz, 0 to -800 mV
