Adjustment Procedures
Table 5-2: Adjustment steps (cont.)
Input Setup diagram
2-ch model
step number
4-ch model
step number Signal Signal source setting
54 54
Sinewave Generator,
50 Ω
5kHz,1V
p-p
55 55
Sinewave Generator,
50 Ω
1 MHz, 100 mV
p-p
56 56
Sinewave Generator,
50 Ω
1MHz,1V
p-p
57 57
Sinewave Generator,
50 Ω
50 kHz, 1 V
p-p
58 58
Sinewave Generator,
50 Ω
20 MHz, 1 V
p-p
59 59
Sinewave Generator,
50 Ω
BWL, 25 mV
p-p
60 60
Sinewave Generator,
50 Ω
BWL, 50 mV
p-p
61 61
Sinewave Generator,
50 Ω
BWL, 100 mV
p-p
62 62
Sinewave Generator,
50 Ω
BWL, 250 mV
p-p
63 63
Sinewave Generator,
50 Ω
BWL, 500 mV
p-p
64 64
Sinewave Generator,
50 Ω
BWL, 1 V
p-p
65 65
Sinewave Generator,
50 Ω
5kHz,2.5V
p-p
66 66
Sinewave Generator,
50 Ω
1MHz,2.5V
p-p
67 67
Sinewave Generator,
50 Ω
50 kHz, 2.5 V
p-p
68 68
Sinewave Generator,
50 Ω
20 MHz, 2.5 V
p-p
69 69
Sinewave Generator,
50 Ω
BWL, 2.5 V
p-p
Ch 2 Sinewave
generator
70 70
Sinewave Generator,
50 Ω
BWL, 5 V
p-p
TDS2000C Series Oscilloscope Service Manual 5–7
