Command Descriptions
2−54
TDS200/1000/2000 Series Oscilloscope Programmer Manual
Table 2−23: Vertical position ranges using a 1X probe
CH<x>:SCAle Position range
2 mV/div ±1000 divs
5 mV/div ±400 divs
10 mV/div ±400 divs
20 mV/div ±400 divs
50 mV/div ±400 divs
100 mV/div ±400 divs
200 mV/div ±10 divs
500 mV/div ±100 divs
1 V/div ±100 divs
2 V/div ±100 divs
5 V/div ±10 divs
CH2:POSition 1.32E0
positions the channel 2 input signal 1.32 divisions above the center
of the display.
CH1:POSition?
might return –1.32E0, indicating that the current position of channel
1 is at –1.32 divisions.
CH<x>:PRObe
Sets or queries the attenuation factor of the specified channel.
Vertical
CH<x>:PRObe { 1 | 10 | 100 | 1000 }
Examples
Group
Syntax
