Command Descriptions
2−58
TDS200/1000/2000 Series Oscilloscope Programmer Manual
menu. Setting the function to anything other than OFF causes the
Cursor menu to be displayed.
NOTE . Setting the display format to XY removes the cursors. Sending
the CURSor:FUNCtion command when the display format is XY
causes the oscilloscope to generate event 221 (Settings conflict) and
leaves the display in XY format.
Cursor
CURSor:FUNCtion { HBArs | OFF | VBArs }
CURSor:FUNCtion?
HBArs specifies horizontal bar cursors that measure the vertical units
in volts, divisions, or decibels (decibels are TDS2MM measurement
module only).
OFF removes the cursors from the display.
VBArs specifies vertical bar cursors that measure time or frequency.
CURSor:FUNCtion VBArs
selects vertical bar type cursors.
CURSor:HBArs? (Query Only)
Returns the current settings for the oscilloscope horizontal bar
cursors.
Cursor
Group
Syntax
Arguments
Examples
Group
