Performance Verification

TDS5000B Series Specifications and Performance Verification

2-3

Click here to change to

menu bar mode

Click here to change to

toolbar mode

Menu bar

Toolbar

Figure 2- 1: Toolbar and menu bar

H The procedures to follow assume that you have connected a mouse to the

oscilloscope so that you can click on the screen controls. If you have not

connected a mouse, you can use the optional touch screen to operate all the

screen controls.
