Tektronix TDS5054B

Performance Tests
2-22
TDS5000B Series Specifications and Performance Verification
TDS 5000B Series Test Record (cont.)
Instrument Serial Number: Certificate Number:
Temperature: RH %:
Date of Calibration: Technician:
TDS5000B Series performance test MaximumOutgoingIncomingMinimum
Channel isolation: 100 MHz
Input to CH 1
CH 2
CH 3
CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
8.00 divisions
0.08 divisions
0.08 divisions
0.08 divisions
Channel isolation: 100 MHz
CH 1
Input to CH 2
CH 3
CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
0.08 divisions
8.00 divisions
0.08 divisions
0.08 divisions
Channel isolation: 100 MHz
CH 1
CH 2
Input to CH 3
CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
0.08 divisions
0.08 divisions
8.00 divisions
0.08 divisions
Channel isolation: 100 MHz
CH 1
CH 2
CH 3
Input to CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
0.08 divisions
0.08 divisions
0.08 divisions
8.00 divisions
Channel isolation: Full Bandwidth
Input to CH 1
CH 2
CH 3
CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
8.00 divisions
0.16 divisions
0.16 divisions
0.16 divisions
Channel isolation: Full Bandwidth
CH 1
Input to CH 2
CH 3
CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
0.16 divisions
8.00 divisions
0.16 divisions
0.16 divisions
Channel isolation: Full Bandwidth
CH 1
CH 2
Input to CH 3
CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
0.16 divisions
0.16 divisions
8.00 divisions
0.16 divisions
Channel isolation: Full Bandwidth
CH 1
CH 2
CH 3
Input to CH 4
N/A
N/A
N/A
N/A
__________
__________
__________
__________
__________
__________
__________
__________
0.16 divisions
0.16 divisions
0.16 divisions
8.00 divisions
