Operating Information
2-2
TLA5000 Series Service Manual
Rear panel
AC Power
Ground connection
Figure 2- 1: Location of the ground connection
The accessory connections are the same as those on a personal computer. The
connection points are shown in Figure 2--2 on page 2 --3.
WARNING. Before installing accessories to connectors (mouse, keyboard, etc.),
power off the logic analyzer. See Powering Off the Logic Analyzer on
page 2--5.
Connect the Accessories
To Next Page
