Tektronix WVR6020 User Manual

Audio Performance Verification
23. Connect the gen
erator balanced (BAL) analog output to the Input A1 XLR
of the breakout cable.
24. Check for an indication of 18 dbu in the corresponding bar.
25. Connect the Output 1 XLR of the breakout cable to the analyzer balanced
(BAL) analog input.
26. Check for an RMS indication of 18 dBu ±1.0dB on the analog analyzer and
record Pass/fail the result in the test record.
27. Repeat the previous step for Ou
tput 3 and Output 5.
28. Connect the generator balanced (BAL) analog output to the Input A2 XLR of
the breakout cable. Press CONFIG to display the CONFIG menu.
29. Check for an indication of 18 dBu in the corresponding bar.
30. Connect the Output 2 XLR of the breakout cable to the analyzer balanced
(BAL) analog input.
31. Check for an RMS indication of 18 dBu ±1.0dB on the analog analyzer and
record the Pass/fail result in the test reco
rd.
32. Repeat the previous step for Output 4 and Output 6. Repeat also for Output 8,
except when checking Option DA-equipped instruments.
33. Set the analog audio generator as follows:
Control or Setting Value
Frequency 19 kHz
Output Level
18 dBu A udio Tone
Output Impedance 10 Ω
34. Connect the generator balanced (BAL) analog output to the Input A1 XLR
of the breakout cable.
35. Check for an indication of 18 dbu in the corresponding bar.
36. Connect the Output 1 XLR of the breakout cable to the analyzer balanced
(BAL) analog input.
37. Check for an RMS indication of 18 dBu ±1.0 dB on the analog analyzer a nd
record the Pass/fail result in the test record.
38. Repeat the previous step for Output 3 and Output 5. Repeat also for Output 7,
except when checking Option DA-equipped instruments.
39. Connect the generator balanced (BAL) analog output to the Input A2 XLR of
the breakout cable. Press CONFIG to display the CONFIG menu.
40. Check for an indication of 18 dbu in the corresponding bar.
41. Connect the Output 2 XLR of the breakout cable to the analyzer balanced
(BAL) analog input.
Waveform Rasterizers Specifications and Performance Verification 123
