Tektronix WVR6020 User Manual

Specifications
Table 10: External reference characteristics (cont.)
Characteristic Performance requirement Reference information
Bi-level sync Remains locked with < 1.0 V
p-p
on
0 dB signal.
Tri-level sync Remains locked with < 0.5 V
p-p
on
0 dB signal.
Lock in Presence of White Noise
Remainslockedonblackburstwith
Signal/Noise ratio of 32 dB, 5 MHz
bandwidth.
Color Framing Correct color framing detected for composite
signals with burst present and having <
45 ° SCH Phase error.
Also applies to internal mode.
Table 11: Miscellaneous measurements and display characteristics
Characteristic Performance requirement Reference information
352M Payload Displays the payload type as indicated by
SMPTE 352M ancillary data.
Shown in the Video Session display.
Ancillary Data
Identifies the presence of ancillary data
(othe
r than EDH).
Shown in the Video Session display.
SDI Vi
deo Format
Indic
ates SDI video format listed in the
section. (See page 33.)
Shown
in the Video Session display.
Stuck Bits Displays the state o f unchanging bits in
the SDI data stream.
Shown in the Video Session display.
Gamut Error Statistics Displays errored seconds and fields, and
per
centage of fields with errors for RGB,
Composite and Luma Gamut errors. (See
Table 21 on page 12.)
Shown in the Video Session display.
Closed Caption Type
Indicates closed caption types detected.
Shown in the Auxiliary D ata Status
di
splay.
V
-Chip Rating
D
isplays the Content Advisory Rating
from the selected EIA608 data stream.
S
hown in the Auxiliary D ata Status
display.
CC Services Lists the Closed Caption Services present
in the s elected EIA608 data stream.
Shown in the Auxiliary D ata Status
display.
Transmission Signal Identifier Displays the TSID present in the selected
EIA608 data stream.
Shown in the Auxiliary D ata Status
display.
Table 12: Timecode characteristics
Characteristic Performance requirement Reference information
Display
Onscreen readout from the selected
timecode type and source appears in the
status bar and in the Error Log.
VITC signal type Vertical Interval Time Code as defined by
SMPTE 12M.
Waveform Rasterizers Specifications and Performance Verification 7

Tektronix WVR6020 Specifications

General

Brand	Tektronix
Model	WVR6020
Category	Measuring Instruments
Language	English
