Tektronix WVR6020 User Manual

Specifications
Signal Input-
to-Reference Compatibility Tables
The following tabels list the signal input and reference formats that are supported
by the instrument. An X indicates supported input and reference combinations.
Blank cells i
n the tables indicate untested combinations.
Table 50: 59.94, 29.97, 23.98 Hz input and reference format combinations
Reference Format
720p 1080p
1080sf
1080p
1080sf
1080i
Input Format
NTSC
23.98 29.97 59.94 23.98 23.98 29.97 29.97 59.94
720p, 23.98 Hz
3
XXXXX
720p, 29.97 Hz
3
XX X
720p, 59.94 Hz
3
XXXXX
1080p, 23.98 Hz
34
XXXXX
1080sf, 23.98 Hz
34
XXXXX
1080p, 29.9
7Hz
34
XX X
1080sf, 29.97 Hz
34
XX X
1035i, 59.94 Hz
3
XX X
1080i, 59.94 Hz
34
XX X
483i, 59.94 Hz (525)
2
XX X
NTSC 59
.94 H z
1
X
1
Available with Option CPS.
2
Available with all instruments (SD).
3
Available with WVR7020 and WVR7120.
4
Includes dual-link standards with Option DL.
Table 51: 60, 30, 24 Hz input and r eference format combinations
Reference F ormat
720p 1080p 1080sf 1080p 1080sf 1080i
InputFormat 2430602424303060
720p, 24 Hz
1
XXX X
720p, 30 Hz
1
XX
720p, 60 Hz
1
XXX X
1080p, 24 Hz
12
XXX X
Waveform Rasterizers Specifications and Performance Verification 3 3
