A.5.7 xDSL interface
STANDARDS
ITU-T G.992.5 (ADSL2+)
• Annex A: ADSL2+ over POTS
• Annex M: ADSL2+ with extended upstream over POTS
• Annex B: ADSL2+ over ISDN
• Annex B: ADSL2+ all digital over ISDN
ITU-T G-993.2 (VDSL2, Annex A and B)
• Profiles: 8a, 8b, 8c, 12a, 12b, 17a, 30a, 35b
ITU-T G-993.5 (VDSL2, vectoring and Super-vectoring)
TRANSPORT MODE
ADSL2+
• ATM (Asynchronous Transfer Model)
VDSL2
• PTM (Packet Transfer Model)
BANDWIDTH
ADSL2+
• Downstream speed: 27 Mbps
• Upstream speed: 3 Mbps
VDSL2
• Downstream speed: Up to 350 Mbps
• Upstream speed: Up to 60 Mbps
CONNECTOR Female RJ45.
A.5.8 Configuration interface
LOCAL TERMINAL RS-232 115200-8-N-1 without flow control.
CONNECTOR Female RJ45.
A.5.9 Power supply
INPUT VOLTAGE +12V DC.
INPUT CURRENT Depending on the model.
• 2.5 A. (TLDPM00F1, TLDPM01F1)
• 3.0 A. (TLDPM02F1, TLDPM03F1)
CONNECTOR Jack 5.5/2.5 mm.
A.5.10 Dimensions and weight
TYPE Desktop / chassis for a 1 U high Rack mount enclosure.
DIMENSION 283mm x 144mm x 40mm
WEIGHT 0.6 Kg
