OUTLET, which should at the same time be of good quality (lower than 10 ohms).
We recommend connecting all data devices to the same power source regardless of whether the work-
place is provided with an uninterrupted power supply (UPS), a regulated supply or is independent of
other power supplies (such as lighting, etc.). This will help to prevent malfunctions and premature aging
of the drivers and other components.
3.4.2 Connecting
• Make sure the on/off power switch is in the OFF position.
• Connect all data cables.
• Connect the power supply to the device.
• Set the device’s on/off power switch in the ON position.
3.4.3 Disconnecting
• Set the on/off power switch in the OFF position.
• Disconnect the power supply from the device.
• Disconnect the data cables.
To connect the power source to the device, follow the steps listed in the previous table: make sure the switch is OFF
(0) and the power supply is NOT connected to the main electricity supply; find the POWER plug (located on the rear
panel of the device) and plug it into the power source using the grounded cable that is supplied for this purpose.
3.5 RESET button
The different features of the RESET button are described below.
3.5.1 Rebooting the device
Once the device is operating normally, pressing the RESET button will force a restart.
3.5.2 Default configuration
The RESET button allows you to boot the device with its default configuration through the following steps:
• With the device switched off, keep the RESET button pressed and switch on the router through the ON/OFF switch
(1).
• The POWER LED (green) will light up and the STATUS LED will begin to blink (green). This blinking will continue
for 10 seconds.
• For the device to boot with the default configuration, stop pressing the RESET button while the STATUS LED is
blinking, i.e., before the 10 second period expires.
The default configuration for the router sets the following access IP and mask addresses:
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
Note
Some devices leave the factory with customized settings. As a result of this personalization, the default
configuration may be different from the one shown above.
3 Components and Power Supply Teldat S.A.
12 RS123 Router
