Teldat RS123w-4G User Manual

Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+. EC25-E specifications.
Bands Frequencies Conducted Transmit Power
Band 1 Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
+24 dBm +1/-3 dB
Band 8 Tx: 880–915 MHz
Rx: 925–960 MHz
+24 dBm +1/-3 dB
Technology: GSM / GPRS / EDGE. MC7304 Specifications
Bands Frequencies Radiated Transmit Power
EGSM 900 (900 MHz) Tx: 880–915 MHz
Rx: 925–960 MHz
+32 dBm ± 1 dBm
DCS 1800 (1800 MHz) Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
+29 dBm ± 1 dBm
Technology: GSM / GPRS / EDGE. EC25-E specifications.
Bands Frequencies Conducted Transmit Power
EGSM 900 (900 MHz) Tx: 880–915 MHz
Rx: 925–960 MHz
+33 dBm ± 2 dB
+27 dBm ± 3 dB (8-PSK)
DCS 1800 (1800 MHz) Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
+30 dBm ± 2 dB
+26 dBm ± 3 dB (8-PSK)
B.2 Radio WI-FI specifications
Wi-Fi Radio communications comply with standards 802.11a/b/g/n.
This product is supplied with antennas. To comply with the regulations, do not choose other antennas.
Standard IEEE 802.11-2016 including 802.11a, 802.11b, 802.11g, 802.11n, 802.11i,
802.11e
Frequency bands 2,4 GHz/5 GHz
Channels and frequencies EU: 802.11b/g/n-HT20: 2412 ~ 2472MHz (channels 1 to 13);
EU: 802.11n-HT40: 2422 ~ 2462MHz (channels 3 to 11);
EU: 802.11a /n-HT20/ac-VHT20: 5180~5240 MHz (channels 36 to 48),
5260~5320 MHz (channels 52 to 64), 5500~5700 MHz (channels 100 to 140);
EU: 802.11n-HT40: 5190~5230 MHz (channels 38 and 46), 5270~5310 MHz
(channels 54 and 62), 5510~5670 MHz (channels 102 to 134) ;
USA: 802.11b/g/n-HT20: 2412 ~ 2462MHz (channels 1 to 11);
USA: 802.11n-HT40: 2422 ~ 2452MHz (channels 3 to 9);
USA: 802.11a /n-HT20: 5180~5240 MHz (channels 36 to 48), 5260~5320 MHz
(channels 52 to 64), 5500~5700 MHz (channels 100 to 140), 5745~5825 MHz
(channels 149 to 165);
Radio Information Teldat S.A.
32 RS123 Router
