Chapter 2: PRODUCT PAGES
CHAPTER2:PRODUCTPAGES
RECEIVERDESCRIPTION
T70RX-03AIB, T70RX-03AWB
WARNING! The receiver must NOT be opened by any other than a qualified installer. Make sure to
turn the electricity off before opening the receiver.
1. Relay LEDs 1-3 6. Code LED (red)
2. Function relays 1-3 7. Power supply LED (yellow)
3. Quick fuse 10A 8. Function LED (green)
4. Terminal block for input power 9. Function button
5. Antenna connector 10. Code button
- 5 -
