90453-02 Rev A0 Telebit Cables C-1
Telebit Cables C
This appendix shows the wiring diagrams for the following Telebit cables
and adapters. The following four items you received with your NetBlazer:
• RS-232 cable (DB-25 male to DB-25 female, p/n 12732-01)
• RS-232 cable (DB-25 male to DB-9 female, p/n 14339-01)
• Null modem (DB-25 male to DB-25 female, p/n 14168-01)
• Gender adapter (DB-25 female to DB-25 female, p/n 14338-01)
The following seven cables are available from Telebit:
• RS-232 cable (DB-26 male to DB-25 male, p/n 12721-01) for the
SYN232 synchronous board
• RS-449 cable (DB-26 male to DB-37 male, p/n 12720-01) for the
SYN449 synchronous board
• V.35 cable (DB-26 male to V.35 male, p/n 12722-01) for the SYN35
synchronous board
• RS-530 cable (DB-26 male to DB-25 male, p/n 13203-01) for the
SYN530 synchronous board
• X.21 cable (DB-26 male to DB-15 male, p/n 14257-01) for the
SYNX21 synchronous board
• V.35 cable (p/n 12079-01) for the NS1 single-port synchronous
board
• NT1 cable RJ-45/RJ-45 (p/n WT-MM1430-006) for the NI2B Dual
BRI board in the U.S. and Canada only.
