Telect ELF-1008-1100 - Figure 1 - ELF Chassis Mounting Options

© Telect, Inc., All Rights Reserved, 124317-10 A0
1.509.926.6000 :: telect.com
6
ELF System
Copper / Fiber :: ELF Family
3.5 (88.9)
5.00 (127.0)
17.25 (438.2)
1.73 (44.0)
Reversible Rack Brackets
Fit 19-in. or 23-in., EIA- or
WECO-Spaced Racks. Brackets
Tie-Down Bar
Removable Cable
Note: Dimensions are in in. (mm)
FRONT VIEW
REAR VIEW
#8-32 Ground Stud and KEPS Nut
can be Positioned for Panel Flush
or 1-in. Extended Mounting.
Figure 1 - ELF Chassis Mounting Options
