780E Video Generator / Analyzer – Quick Start Guide Page 3
September 13, 2018
P/N 68-00231 - Rev. B1
780E Front Edge
780E Rear Edge
1.3 What is in the 780E shipping box?
The 780E instrument shipping container includes the items listed in Table 1-1 below:
Table 1-1: 780E Shipping Box Contents
Item Description
Part No.
780E Video Generator / Analyzer. (Includes DisplayPort interfaces as a standard feature)
00-00243
780E Video Generator / Analyzer. (DisplayPort interfaces are an optional feature)
00-00251
12V DC (5 amp) Power Supply / Adapter / Charger.
25-00110
Line cord for 12V Power Supply.
30A00400A03
Cable: HDMI-to-HDMI Type A.
30-00146
Cable: DP-to-DP Standard. (Not included with 780E P/N 00-00251)
30-00162
Cable: USB.
30-00163
