Video Resolution Status
Indicates the video resolution on the HDMI In port.
This includes:
 Horizontal Active in pixels
 Vertical Active in pixels
 Frame rate
Video Identification Status
Indicates the CEA video identification code.
3D Status
Indicates the status of 3D video. This includes:
 3D enabled or disabled
 3D format
AVmute Status
Indicates the AVmute status, enabled or disabled.
HDCP Status
Indicates whether the incoming HDMI video is
encrypted with HDCP.
+5V Status
Indicates whether +5V is detected from the source.
OUT
Video Type
Status/Selection
Indicates the video on the video Out ports. This
includes:
 Video interface: HDMI, DVI, DisplayPort,
HDBaseT
Provides access to the Video Signal Type screen.
Video Resolution
Status/Selection
Indicates the video resolution on the video interface
Out port. This includes:
 Horizontal Active in pixels
 Vertical Active in pixels
 Frame rate
Provides access to the Video Format screen.
Video Pattern
Status/Selection
Indicates the video pattern on the HDMI Out port.
Provides access to the Video Pattern screen.
3D Format
Status/Configuration
Indicates the status of 3D video (applies to HDMI
and HDBaseT). This includes:
 3D enabled or disabled
 3D format
Provides access to the 3D video configuration
screen.
Audio Status
Indicates the Audio status:
 Audio format
 Audio channels
 Audio sampling rate
HDCP Status
Indicates whether the incoming video on the HDMI,
HDBaseT and DisplayPort In port is encrypted with
HDCP.
