780E Video Generator / Analyzer – Quick Start Guide Page 10
AVMute
HDCP Status
+5V Status
Indicates the status of:
AVMute active/inactive status
HDCP active/inactive status
+5V present/not present status
3.4 Running Basic Tests on Sink Devices
This Quick Start Guide does not cover detailed procedures for most common operations. However, the following
information will get you started conducting some of the more common operations for testing sinks.
1. To set the signal type, touch select the Interface button from the Home menu as shown below:
2. To select the video resolution, touch select the Format button from the Home menu as shown below:
To Next Page
