Introduction MX300
Teledyne Analytical Instruments 4
 Rugged high impact ABS plastic construction
 Splash resistant case.
 Long life class R17MED sensor
 0-1 VDC digital output (optional RS-232)
 FDA 510(k) market clearance
1.2 Options
The following options are available for the MX300 Monitor:
 A-Option—2½-digit LCD instead of 3½-digit
NOTE: CONTACT FACTORY FOR MODIFYING YOUR MONITOR FOR 2½-
DIGIT LCD. FOR RS-232 RECONFIGURATION, SEE SECTION 2.1.5.

B-Option—RS 232 digital output instead of 0-1VDC
 Universal Pole Mounting Clamp (P/N CP 2345)
 V-Mount Pole Clamp (P/N CP 2344)
 V-Mount Wall Adapter P/N B 647)
 0-1 VDC Interface Cable (P/NB-75554)
 RS 232 Interface Cable (P/N B-75555)
1.3 Applications
The MX300 Monitor is intended for spot checking the concentra-
tion of oxygen in gas mixtures used in applications such as Anesthesia
gas delivery and Respiratory care, and is intended for adult, pediatric
and neonatal populations.
1.4 Operation Summary
The MX300 Monitor uses Teledyne Analytical Instruments’ Pa-
tented R17MED oxygen sensor. The sensor output is used to determine
the oxygen gas concentration. The data from the sensor is compared to
the alarm values set by the user, and activates the audible and visual
alarms if the oxygen level crosses the threshold values. Sensor
fail/disconnect alarm is incorporated in the Monitor to warn the user of a
sensor problem. TheSENSOR indicator is illuminated on the LCD and
the audible and visual alarms are activated whenever a fault is detected.
