30
2.1.1.- Single-channel configuration
It is possible to select the inputs and channels for each single-channel.
The possible inputs are:
9-0: The first 9 single-channels are assigned to the UHF1 input and there is no
single-channel in the UHF2 input.
7-2: The first 7 single-channels are assigned to the UHF1 input and the 8 & 9
single-channels are assigned to UHF2 input.
6-3: The first 6 single-channels are assigned to the UHF1 input and the 7, 8 & 9
single-channels are assigned to UHF2 input.
The single-channel 10 always are assigned to the UHF3 / DTT input.
“Single-channel x” option
Configure each of the single-channels (1 to 10) with the desired UHF channel
(21 to 69 or from 21 to 66 if the Avant is a digital unit). When one of the single-
channels is not in use, it is necessary to switch it off by selecting the “Off” option.
