Televes SmartKom 531981 User Manual

EN
5
REF.531980 - SMARTKOM MAST AMPLIFIER 3x VHF+UHF
Frequency range
MHz 54-88 / 174-216 / 470-608
Input Dynamic Range dBmV -20...+30
Maximum gain dB -
Gain regulation dB AGC
Num. of lters - 32
Channel/lter programming - Lo-V: 2 - 6 / Hi-V: 7 - 13 / UHF: 14 - 36
Filtered channel level
regulation
dB AGC per lter
Selectivity dB >50 (+/-6MHz) *
Output level dBmV UHF => 25 / VHF => 22
Vout regulation dBmV UHF => 0...25 / VHF => -3... +22
Chs per lter - 1
Manual regulation dB
+ 3
Inputs powering
V
12 (AUTO / ON / OFF)
mA 70 ( per input )
Max consumption mA 500 @12V= (W/O DC IN)
Temperature ºC / ºF - 5... +45 / 23...113
Dimensions mm / in 137 x 128 x 45 / 5.39 x 5.03 x 177
Weight g / lb 400 / 0.88
IP - 23
3. TECHNICAL SPECIFICATIONS
(*) Adjacent channels interference rejection >30dB (+/-1MHz)
REF.550280 - POWER SUPPLY
TV - MIX
Frequency range
MHz 47 - 862
Insertion losses dB <2
Output voltage V
12
Maximum current mA 750
Mains voltage
V~
110 - 120
Maximum consumption
W
14
Maximum current
mA~
200
Temperature
ºC / ºF
- 5... +45 / 23... 113
Dimensions
mm / in
146 x 53 x 35 / 5.74 x 2.08 x 1.37
Weight
g / lb
286 / 0.63
IP
-
20
