4-T 4-U
4-V 4-W
Toggle the retarder and put it in a vertical
position.
Retarder in a vertical position
Axle side
Axle side
Toggle again the retarder (axle side up) to
the wood bars in order to check the stator run
out.
Check the run out of the stator by using a
magnetic dial gauge and a sensor.
Maximum value allowed is 0.40 mm.
Nota: In case the maximum value is up to
0.40mm, contact technical department at
TELMA SA.
