Micro-SIM card insertion/removal must be performed when device is powered off –
external voltage and internal battery disconnected. Otherwise Micro-SIM card might be
damaged or device will not detect it.
Socket pinout
PIN
NUMBER
PIN NAME DESCRIPTION
1
VCC (10-32)V
DC (+)
Power supply (+10-32 V
DC).
2 RS232 GND RS232 Ground pin.
3 RS232-TX Output for data transmit
through RS232.
4 USB DATA + Differential serial data +
5 USB DATA- Differential serial data -
6
GND (-)
Ground.
7 AIN1 Analog input, channel 1.
Input range: 0-30 V DC.
8 RS232-RX Input for data receive
through RS232
9 USB GND Ground PIN for USB
10 USB +5V Ground PIN for USB
Wiring scheme
For the more detailed MSP500 device wiring, see the scheme below.
PC Connection (Windows)
Power-up MSP500 with DC voltage 10-30 V power supply using supplied power cable.1.
LED’s should start blinking, see “MSP500 LED status”.
Connect device to computer using USB B-Type cable connection:2.
Using USB B-Type cable
You will need to install USB drivers, see "How to install USB drivers
(Windows)"
You are now ready to use the device on your computer.3.
How to install USB drivers (Windows)
Please download COM port drivers from Teltonika here.1.
Extract and run TeltonikaCOMDriver.exe.2.
Click Next in driver installation window.3.
In the following window click Install button.4.
Setup will continue installing the driver and eventually the confirmation window will appear.5.
Click Finish to complete the setup.
