Teltonika RUT500 User Manual

9
Back Panel
1
GSM main antenna connector
2
Wi-Fi antenna connector
3
GSM auxiliary antenna connector
4
Reset button
5
GSM LED
SIM Card
1. Remove back panel and insert SIM card which was given by your ISP (Internet Service Provider). Correct SIM
card orientation is shown in the picture.
2. Attach GSM main and Wi-Fi antennas.
3. Connect the power adapter to the socket on the front panel of the device. Then plug the other end of the power
adapter into a wall outlet or power strip.
4. Connect to the device wirelessly (SSID: Teltonika) or use Ethernet cable and plug it into any LAN Ethernet port.
Logging in
Afte oue oplete ith the settig up as desied i the setio aoe, ou ae ead to stat loggig ito ou
router and start configuring it. This example shows how to connect on Windows 7. On windows Vista: click Start ->
Control Panel -> Network and Sharing Centre -> Manage network Connections -> (Go to step 4). On Windows XP: Click
www.ddszevenbergen.nl

Teltonika RUT500 Specifications

General

Brand	Teltonika
Model	RUT500
Category	Network Router
Language	English
