Teltonika RUT900 User Manual

6.7.3 Traffic
This tri-graph illustrates average system load over the course of ~3 minutes; each new measurement is taken
every 3 seconds. The graph consists out of three color coded graphs, each one corresponding to the average system
load over 1 (red), 5 (orange) and 15 (yellow) most recent minutes. Although not graphed, the page also displays peak
loads over 1, 5 and 15 minutes.
Field Name
Explanation
1.
Bridge
Cumulative graph, which encompasses wired Ethernet LAN and the wireless network.
2.
LAN
Graphs the total traffic that passes through both LAN network interfaces.
3.
WAN (Wired)
Graphs the amount of traffic which passed through the current active WAN connection.
4.
Mobile
Graphs the amount of traffic which passed through the mobile network connection.
5.
Wi-Fi
Shows the amount of traffic that has been sent and received through the wireless radio.
36
